complete intermedate planetary gear set
220 270 09 26 planetary with 4 planetary gears 23 teeth each, height 342,2mm, output shaft 30 splines
ring gear 76 teeth
220 272 05 07 sun gear 28 teeth, OD between needle bearing and sungear = 48,25mm, height 142,2mm, 56 splines

used part - quality: signs of use, item might need some work on it.- can be ordered only if in stock - subject to prior sale.

If bearings, bushings, seals, gaskets and washers are supplied they are free of charge as they may have to be replaced - missing or damaged items of this kind will not be replaced by us.

All used parts are delivered without warranty.

Various executions of this part are available for these transmissions

PLEASE CHECK CAREFULLY BEFORE INSTALLATION. WE WILL NOT TAKE RESPONSIBILITY FOR DAMAGES RESULTING FROM THE INSTALLATION OF A WRONG SPARE PART/COMPONENT.

The distinguishing features known to us to this day are stored for each article.

intermediate planetary

1

722.9
